Smarter Smart Meter and Edge-AI Data Logger Design with MRAM

A modern smart meter design integrates MRAM as the non-volatile memory core alongside key processing and communication components. This architecture supports OTA updates, local AI-based decision-making, and power-efficient operation.

The architecture of an AI-enhanced smart meter integrating MRAM (Fig.1) is built around a modular embedded system comprising five principal components: a microcontroller unit (MCU), MRAM for non-volatile memory, an AI accelerator, a power management unit (PMU), and the metering/load interface. This configuration is designed to deliver high-performance, energy-efficient data acquisition, processing, and logging in edge environments.

At the core, the microcontroller serves as the system's command center, orchestrating data flow, managing peripheral interfaces, and executing firmware tasks including real-time metering, communication handling, and power control. It is connected to MRAM, which acts as the primary non-volatile memory. MRAM offers byte-level access, write endurance exceeding 10¹⁴ cycles, and data retention beyond 10 years without the need for refresh cycles or wear-leveling algorithms, making it vastly superior to EEPROM or Flash in this context. The fast access time (~10 ns) also supports OTA firmware updates and instantaneous data logging.

The AI accelerator, tightly coupled with the MCU via digital I/O or memory-mapped interfaces, performs local inferencing tasks such as anomaly detection, consumption forecasting, and pattern recognition, enabling autonomous edge intelligence without reliance on cloud processing. The outputs of these computations can be stored in MRAM, ensuring secure and persistent retention of inference results or model updates.

Supporting these processing elements, the power management unit provides a regulated supply voltage derived from either mains or battery sources. The PMU incorporates diodes and filter capacitors to protect against surges and reverse polarity while optimizing power sequencing to minimize consumption during standby. This allows the system to operate with ultra-low power budgets—critical for remote and battery-operated deployments.

The metering interface connects analog front-end sensors, such as current transformers (CTs) and voltage dividers to the system, enabling accurate sampling of real-time electrical parameters. The MCU processes this data and, when needed, triggers AI-based evaluations or control actions. The system also includes a load control mechanism, allowing it to modulate or disconnect loads based on predefined rules or learned behavior.

Overall, the architecture delivers a high degree of integration and resilience. It enables persistent, high-speed data logging, real-time control, and AI-driven analytics in a compact, energy-efficient platform. The use of MRAM eliminates conventional NVM bottlenecks, while the AI accelerator ensures the system can adapt and respond intelligently to dynamic operating conditions. This makes it ideally suited for next-generation smart meters deployed in both residential and industrial energy monitoring systems.
